MSCT-MS060TPL012TC02A3-CR150

Data Sheet Request add to Inquiry Cart Back

CR150 is ideal for failure analysis below 180nm technology process.
Standard type has better durability.

Available on Hitachi Nano probing system.
No need to proceed Chemical Clean Process.
Have SEM inspection before packing.
Tip Resistance is under 50ohm.
Have MESOSCOPE unique MST(Micro Surface Treatment) process to increase tip uniformity.
Longer Cone Shrink Length for improving working aspect.
Available to be measured below 180nm device

Material	Tungsten	Coating Material	NA
Wire Diameter ( WD)	0.25mm	Total Probe Length(TPL)	12mm
Tape Cone ( TC)	2mm	Capillary Diameter(CD)	0.6mm
Tape Cone Angle Type	A3	Curvature Radius(CR)	<150nm
Suitable for measuring Process	≤180nm Manufacturing Process

MSCT	-	MS	060	TPL012	TC02	-	A3	CR150
		(1)	(2)	(3)	(4)		(5)	(6)

Probe application type: MS is for Hitachi SEM based electrical nano-probing application.
Copper Tube Diameter (CTD): 0.6mm
Total probe length (TPL): 12mm
Tape Cone length (TC): 2mm.
Cone Angle type: A3
Available option: A2, A3
Curvature radius (CR): <150nm.
Diameter at position of 100nm below apex is in the range of 200nm to 350nm.
